GLOBE GP9-12 (12V 9Ah) battery

the GIGA GP9-12 (12V 9Ah) battery is designed for reliable power backup systems using Absorbent Glass Mat (AGM) technology. This battery is maintenance-free and ensures stable power output. It’s ideal for various applications, including uninterruptible power supplies (UPS), medical equipment, telecommunication systems, and emergency power systems. With a heavy-duty grid, it provides durability, while its sealed design prevents spills and leakage.

This battery complies with major safety and quality standards, including IEC, BS, JIS, Eurobat, UL (MH62092), and CE certifications. It offers a floating design life of 5 years at 25°C, making it a dependable solution for critical systems that require continuous power.

Key Features:
Nominal Voltage: 12V
Capacity: 9.0Ah at 20-hour rate
Dimensions: 151mm x 65mm x 94mm (L x W x H)
Weight: 2.35kg (± 3%)
Max Charge Current: 2.70A
Max Discharge Current: 135A (5 seconds)
Short-Circuit Current: 360A
Internal Resistance: 18.5mΩ (full charge at 25°C)
Operating Temperature Range:
Discharge: -15°C to 50°C
Charge & Storage: -15°C to 40°C
Design Features:
Heavy-duty grid for durability
AGM technology for reliable power output
Sealed, maintenance-free design
Long life and low self-discharge
Safety valve to prevent overpressure
Non-spillable construction for maximum safety
Applications:
Uninterruptible Power Supplies (UPS)
Telecommunications systems
Medical equipment
Emergency power systems
Alarm systems
Electric vehicles
Power tools
Capacity at 25°C:
20-hour rate (0.45A, 10.5V): 9.00Ah
10-hour rate (0.837A, 10.5V): 8.37Ah
3-hour rate (2.25A, 10.2V): 6.75Ah
1-hour rate (5.71A, 9.6V): 5.71Ah
Specifications:
Charge Voltage:
Float Charging Voltage: 13.5 – 13.8V at 25°C
Equalization Charging Voltage: 14.4 – 15.0V at 25°C
Terminal Type: Copper
Cycle Use Charging: 14.5 – 15.0V
Standby Use Charging: 13.5 – 13.8V
